How to configure Outbound NSG for application gateway
heng yeow (nova)
90
Reputation points
I want to configure the custom error pages for my listener in application gateway. The static .html page is in another VM which is different virtual network with application gateway.
When running the "connection troubleshoot" tool, I noticed the "Outbound NSG diagnostic" status is Denny. How to resolve it?
Please refer to the information below:
My application gateway firewall is using "Standard V2".
My application gate way's Virtual network/subnet : fornaxNet / fornaxNetSub
I have created Peerings to connect to the VM (in another Virtual network)
The VM is in Virtual network/subnet : SPD-SIT-Network/SPD-SIT-Subnet1
Have also created the Peering.
